Part Number :
SA5534AP
Manufacturer :
Texas Instruments
Description :
SA5534AP datasheet pdf and Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps product details from Texas Instruments stock available at Rozee
Lifecycle :
New from this manufacturer
Delivery :
DHL、UPS、FedEx、Registered Mail
Payment :
T/T Paypal Visa MoneyGram Western Union
More Information :
SA5534AP More Information
ECAD :
Request Free CAD Models
Pricing(USD) :
$1.27
Remark :
Manufacturer: Texas Instruments.
Rozee is one of the Distributors.
Wide range of applications.
Width :
6.35 mm
Length :
9.81 mm
Slew Rate :
13 V/µs
Case/Package :
PDIP
Number of Pins :
8
Max I/O Voltage :
4 mV
Number of Channels :
1
Gain Bandwidth Product :
10 MHz
Max Dual Supply Voltage :
15 V
Operating Supply Current :
4 mA
Max Operating Temperature :
85 °C
Input Offset Voltage (Vos) :
500 µV
Common Mode Rejection Ratio :
70 dB
Products Category :
Integrated Circuits (ICs) - Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Qty :
4571 In Stock
Applications :
Motor drives
Home theater & entertainment
Wired networking
Height :
5.08 mm
Bandwidth :
10 MHz
Thickness :
3.9 mm
Voltage Gain :
100 dB
Output Current :
38 mA
Input Bias Current :
1.5 µA
Number of Circuits :
1
Nominal Supply Current :
8 mA
Min Dual Supply Voltage :
5 V
Operating Supply Voltage :
15 V
Min Operating Temperature :
-40 °C
Output Current per Channel :
38 mA
Nominal Gain Bandwidth Product :
10 MHz
